Reference     design

Part Number

Key feature

Charger 3.5W

5V/0.7A

OB25132

l Standby power less than   50mW@264Vac

l No RCD and output diode   RC snubber

l Integrated BJT Switch

Charger 5W

5V/1.0A

OB25113

l Standby   power less   than 50mW@264Vac

l Cost   effective and   simplified system design

l Integrated BJT Switch

Charger   10W

5V/2.0A

OB25115OB2011E

l Standby   power less   than 75mW@264Vac

l Cost   effective and   simplified system design

l Integrated   BJT   Switch

Charger   10W

5V/2.4A

OB25136 + OB2001Z

l Standby   power less   than 75mW@264Vac

l PSR+Synchronous     rectification for high efficiency

l Integrated BJT Switch   Integrated BJT     Switch

Charger   10W

5V/1.0A

OB2500N

l Standby   power less   than 75mW@264Vac

l Average   efficiency   meet DOE/COC

l Integrated   Power   MOSFET Switch

Charger   10W

5V/2.0A

OB2500P

l Standby   power less   than 75mW@264Vac

l Cost   effective and   simplified system design

l Integrated Power MOSFET   Switch

Charger   10W

5V/2.0A

OB2502P + OB2005V

l Standby   power less   than 75mW@264Vac

l Cost   effective and   simplified system design

l Integrated Power MOSFET   Switch
