| Car Charger | |||||||||||||
| Reference Design | Part No. | Vin(V) | Iq(mA) | Output Port | Freq_Max | Vout Accuracy | Vin_OVP(V) | Vin_UVLO(V) | Cable Compensation | OCP | OTP | Package | |
| 5.2V/3.4A | OB2150CP DBM | OB2150CP | 8~32 | 1.8 | USB-A | 160KHz | ±1.5% | 33.4/32.4 | 7.5/7 | Yes | Yes | Yes | ESOP8 |
| 9V/2A | |||||||||||||
| 12V/2A | |||||||||||||
| 5.2V/3.4A | OB2151VS DBM | OB2151VS | 8~32 | 1.8 | Type-C | 160KHz | ±1.5% | 33.4/32.4 | 7.5/7 | Yes | Yes | Yes | ETSSOP16 |
| 9V/2.22A | |||||||||||||
| 12V/2A | |||||||||||||
| 5V/3.7A | OB2156VS DBM | OB2156VS | 7.5~32 | 1.8 | USB-A &Type-C | 160KHz | ±1.5% | 33.4/32.4 | 7.5/7 | Yes | Yes | Yes | ETSSOP16 |
| 9V/2.7A | |||||||||||||
| 12V/2.7A | |||||||||||||
| 5V/4A | USB A | OB2158VT | 9.5~30 | 2 | USB-A/Type-C | 125KHz | ±1.5% | 30.5/26 | 8.6/8.1 | Yes | Yes | Yes | ETSSOP20 |
| 9V/2.5A | Type C | ||||||||||||
| 12V/2.5A | USB A+Type C | ||||||||||||
| Power Bank | ||||||||||||||
| Reference Design | Part No. | Vin(V) | Isleep mode(uA) | MCU Core | Freq_Max | LDO | Vin_OVP(V) | Vbat OVP | Vbat UVP(V) | Vbat OCP&SCP | OTP_bat | Vout_OVP(V) | OTP_IC | Package |
| 5V/2.4A | OB2112U | 5 | 30 | 8Bit 8051 | 300KHz | 3.3V/50mA | 6 | Yes | 2.8 | Yes | Yes | 6 | Yes | TSSOP20 |
| 5V/2.4A | OB2112V | 5 | 30 | 8Bit 8051 | 300KHz | 3.3V/50mA | 6 | Yes | 2.8 | Yes | Yes | 6 | Yes | TSSOP28 |
| 5V/2.4A | OB2112Y | 5 | 30 | 8Bit 8051 | 300KHz | 3.3V/50mA | 6 | Yes | 2.8 | Yes | Yes | 6 | Yes | TSSOP24 |
| 5V/3.1A | OB2113VK | 5 | 30 | / | 600KHz | / | 6 | Yes | 2.8 | Yes | Yes | 6 | Yes | TSSOP24 |
| 5V/3.8A | OB2122FQ | 5~9 | 30 | / | 400KHz | 5V/80mA | 11.5 | Yes | 2.8 | Yes | Yes | 14.3 | Yes | QFN48 |
| 9V/2A | ||||||||||||||
| 12V/1.5A | ||||||||||||||
| 5V/3.8A | OB2126FQ | 5~9 | 30 | / | 400KHz | 5V/80mA | 11.5 | Yes | 2.8 | Yes | Yes | 14.3 | Yes | QFN48 |
| 9V/2A | ||||||||||||||
| 12V/1.5A | ||||||||||||||
