| Motor Application | |||||||||||||||||
| Part No. | MCU Core | HIRC(MHz) | Flash | RAM | PWM | GPIO | OPA | CMP | ADC | VCC(V) | VCC_UVLO(V) | VCC_OVP(V) | LDO | Gate Driver | VB_UVLO(V) | VB_Max(V) | Package |
| OB6606VG | 1T-8Bit | 16 | 8K | 512B | 2 | 8 | 1 | 1 | 5 | 5~22 | 4.75/4.5 | 25 | 5V/50mA | 1N | / | / | TSSOP16 |
| OB6606VI | 1T-8Bit | 16 | 8K | 512B | 3 | 12 | 1 | 1 | 7 | 5~22 | 4.75/4.5 | 25 | 5V/50mA | 1N | / | / | TSSOP20 |
| OB6606VK | 1T-8Bit | 16 | 8K | 512B | 4 | 14 | 1 | 1 | 8 | 5~22 | 4.75/4.5 | 25 | 5V/50mA | 1N | / | / | TSSOP24 |
| OB6610 | 1T-8Bit | 22 | 16K | 1K+256B | 8 | 30 | / | 3 | 8 | 1.8~5.5 | / | / | / | / | / | / | LQFP32 |
| OB6611FL | 1T-8Bit | 22 | 16K | 1K+256B | 6 | 22 | / | 3 | 7 | 5~28 | 4.5/4 | 37 | 5V/15mA | 3P+3N | / | / | QFN28 |
| OB6611VL | 1T-8Bit | 22 | 16K | 1K+256B | 6 | 22 | / | 3 | 7 | 5~28 | 4.5/4 | 37 | 5V/15mA | 3P+3N | / | / | TSSOP28 |
| OB6612VL | 1T-8bit | 22 | 16K | 1K+256B | 6 | 18 | 1 | 3 | 7 | 5~28 | 4.5/4 | 37 | 5V/100mA | 3P+3N | / | / | TSSOP28 |
| OB6612GQ | 1T-8bit | 22 | 16K | 1K+256B | 8 | 23 | 1 | 3 | 8 | 5~28 | 4.5/4 | 37 | 5V/100mA | 3P+3N | / | / | LQFP48 |
| OB6615AV | 1T-8bit | 22 | 16K | 1K+256B | 6 | 7 | / | 3 | 7 | 5~17 | 4.6/4 | 19.2 | 5V/100mA | 6N | 3.5/2.9 | 71 | TSSOP24 |
| OB6615FL | 1T-8bit | 22 | 16K | 1K+256B | 6 | 9 | / | 3 | 9 | 5~17 | 4.6/4 | 19.2 | 5V/100mA | 6N | 3.5/2.9 | 71 | QFN28 |
| OB6617LGQ | 1T-8bit | 22 | 16K | 1K+256B | 8 | 23 | 1 | 3 | 8 | 5~15 | 4.6/4.4 | 17 | 5V/100mA | 6N | 4/3.7 | 65 | LQFP48 |
| OB6617LFQ | 1T-8bit | 22 | 16K | 1K+256B | 8 | 23 | 1 | 3 | 8 | 5~15 | 4.6/4.4 | 17 | 5V/100mA | 6N | 3/3.7 | 65 | QFN48 |
| OB6617G | 1T-8bit | 22 | 16K | 1K+256B | 8 | 23 | 1 | 3 | 8 | 10~15 | 10/8.9 | 17 | 5V/100mA | 6N | 9/8 | 85 | LQFP48 |
| OB6617HG | 1T-8bit | 22 | 16K | 1K+256B | 8 | 23 | 1 | 3 | 8 | 10~17 | 8.5/7.5 | 19.5 | 5V/100mA | 6N | 8.5/8 | 150 | LQFP48 |
| OB6617PGQ | M0-32bit | 50 | 32K | 4K | 8 | 20 | 3 | 3 | 11 | 5~18 | 4.6/4.4 | 20 | 5V/100mA | 6N | 3.9/3.75 | 70 | LQFP48 |
| OB6619GQ | 1T-8bit | 24 | 16K | 256B+512B | 7 | 23 | 1 | 2 | 13 | 5~18 | 4.6/4.4 | 20 | 5V/100mA | 6N | 3.9/3.75 | 70 | LQFP48 |
| OB6625VI | M0-32bit | 72 | 32K | 4K | 6 | 10 | 1 | 1 | 5 | 5~32 | 4.5/4 | 39 | 5V/100mA | 3P+3N | / | / | TSSOP20 |
| OB6625VK | M0-32bit | 72 | 32K | 4K | 6 | 14 | 3 | 3 | 7 | 5~32 | 4.5/4 | 39 | 5V/100mA | 3P+3N | / | / | TSSOP24 |
| OB6625FL | M0-32bit | 72 | 32K | 4K | 6 | 19 | 3 | 3 | 9 | 5~32 | 4.5/4 | 39 | 5V/100mA | 3P+3N | / | / | QFN28 |
| OB6627GP | M0-32bit | 50 | 32K | 4K | 8 | 21 | 3 | 3 | 10 | 10~15 | 10/8.9 | 17 | 5V/100mA | 6N | 9/8 | 85 | LQFP44 |
| OB6627GQ | M0-32bit | 50 | 32K | 4K | 8 | 23 | 3 | 3 | 12 | 10~15 | 10/8.9 | 17 | 5V/100mA | 6N | 9/8 | 85 | LQFP48 |
| OB6627LGP | M0-32bit | 50 | 32K | 4K | 8 | 21 | 3 | 3 | 10 | 5~15 | 4.6/4.4 | 17 | 5V/100mA | 6N | 4/3.7 | 65 | LQFP44 |
| OB6627LGQ | M0-32bit | 50 | 32K | 4K | 8 | 23 | 3 | 3 | 12 | 5~15 | 4.6/4.4 | 17 | 5V/100mA | 6N | 4/3.7 | 65 | LQFP48 |
| OB6627PGP | M0-32bit | 50 | 32K | 4K | 8 | 21 | 3 | 3 | 10 | 5~18 | 4.6/4.4 | 20 | 5V/100mA | 6N | 3.9/3.75 | 70 | LQFP44 |
| OB6627PGQ | M0-32bit | 50 | 32K | 4K | 8 | 23 | 3 | 3 | 12 | 5~18 | 4.6/4.4 | 20 | 5V/100mA | 6N | 3.9/3.75 | 70 | LQFP48 |
| OB6627HGQ | M0-32bit | 50 | 32K | 4K | 8 | 23 | 3 | 3 | 12 | 10~18 | 8.5/7.5 | 19 | 5V/100mA | 6N | 7.5/7 | 150 | LQFP48 |
| OB6628LGQ | M0-32bit | 72 | 32K | 4K | 6 | 22 | 3 | 3 | 12 | 5~18 | 4.6/4.4 | 20 | 5V/100mA | 6N | 3.9/3.75 | 70 | LQFP48 |
| Small Home Appliances | |||||||||||||||||||
| Part No. | MCU Core | HIRC (MHz) | Flash | RAM | GPIO | ADC | Timer | INT | OPA | ZCD | HV Driver | LED Driver | IGBT Driver | Touch Key | VCC(V) | VCC_UVLO(V) | LDO | Package | Application |
| OB5510CG | 1T-8Bit | 16 | 8K | 512B | 7 | 2 | 3 | 2 | / | / | 5 | / | / | / | 7.5~12 | 7/5.4 | 5V/200mA | SOP16 | 卫浴吊顶 |
| OB5510CI | 1T-8Bit | 16 | 8K | 512B | 11 | 3 | 3 | 2 | / | / | 5 | / | / | / | 7.5~12 | 7/5.4 | 5V/200mA | SOP20 | 卫浴吊顶 |
| OB5511CG | 1T-8Bit | 16 | 8K | 512B | 7 | 2 | 3 | 1 | 1 | 1 | 5 | / | / | / | 6.5~12 | 7/5.4 | 5V/200mA | SOP16 | 电热 |
| OB5515CL | 1T-8Bit | 16 | 16K | 256B+512B | 19 | 8 | 3 | 2 | 1 | 2 | 5 | Yes | / | / | 7.5~12 | 7/5.4 | 5V/200mA | SOP28 | 破壁机 |
| OB5516GN | 1T-8Bit | 16 | 32K | 256B+1K | 23 | 8 | 4 | 2 | 1 | 2 | 5 | Yes | / | 8 | 7.5~12 | 7/5.4 | 5V/200mA | LQFP32 | 豆浆机 |
| OB5516CL | 1T-8Bit | 16 | 32K | 256B+1K | 19 | 8 | 4 | 2 | 1 | 2 | 5 | Yes | / | 8 | 7.5~12 | 7/5.4 | 5V/200mA | SOP28 | 豆浆机 |
| OB5516CI | 1T-8Bit | 16 | 32K | 256B+1K | 11 | 5 | 4 | 1 | 1 | 2 | 5 | Yes | / | 4 | 7.5~12 | 7/5.4 | 5V/200mA | SOP20 | 豆浆机 |
| OB5517CI | 1T-8Bit | 16 | 16K | 256B+1K | 13 | 7 | 4 | 2 | 1 | 1 | / | Yes | / | 9 | 2.4~5.5 | / | / | SOP20 | 豆浆机 |
| OB5517CL | 1T-8Bit | 16 | 16K | 256B+1K | 20 | 8 | 4 | 2 | 1 | 1 | / | Yes | / | 12 | 2.4~5.5 | / | / | SOP28 | 豆浆机 |
| OB5518CI | 1T-8Bit | 8 | 8K | 256B+1K | 6 | 3 | 4 | 1 | / | / | 10 | / | / | / | 7.5~12 | 7/5.4 | 5V/200mA | SOP20 | 卫浴吊顶 |
| OB6652CK | 1T-8Bit | 22 | 16K | 512B | 7 | 5 | 3 | 2 | 1 | 2 | 3 | / | 1 | / | 15~20 | 13.5//13 | 5V/100mA | SOP24 | 电磁炉 |
| OB6654CG | 1T-8Bit | 8 | 8K | 256B | 12 | 8 | 4 | 2 | 1 | 2 | / | / | 1 | / | 12~22 | 10.5/10 | 5V/100mA | SOP16 | 电磁炉 |
| OB6654CI | 1T-8Bit | 8 | 8K | 256B | 14 | 8 | 4 | 2 | 1 | 2 | 1 | / | 1 | / | 12~22 | 10.5/10 | 5V/100mA | SOP20 | 电磁炉 |
| Power Bank | ||||||||||||||
| Part No. | Vin(V) | Vout_Max | Isleep mode(uA) | MCU Core | Freq_Max | LDO | Vin_OVP(V) | Vbat OVP | Vbat UVP(V) | Vbat OCP&SCP | OTP_bat | Vout_OVP(V) | OTP_IC | Package |
| OB2112U | 5 | 5V/2.4A | 30 | 8Bit 8051 | 300KHz | 3.3V/50mA | 6 | Yes | 2.8 | Yes | Yes | 6 | Yes | TSSOP20 |
| OB2112V | 5 | 5V/2.4A | 30 | 8Bit 8051 | 300KHz | 3.3V/50mA | 6 | Yes | 2.8 | Yes | Yes | 6 | Yes | TSSOP28 |
| OB2112Y | 5 | 5V/2.4A | 30 | 8Bit 8051 | 300KHz | 3.3V/50mA | 6 | Yes | 2.8 | Yes | Yes | 6 | Yes | TSSOP24 |
| OB2113VK | 5 | 5V/3.1A | 30 | / | 600KHz | / | 6 | Yes | 2.8 | Yes | Yes | 6 | Yes | TSSOP24 |
| OB2122FQ | 5~9 | 5V/3.8A | 30 | / | 400KHz | 5V/80mA | 11.5 | Yes | 2.8 | Yes | Yes | 14.3 | Yes | QFN48 |
| 9V/2A | ||||||||||||||
| 12V/1.5A | ||||||||||||||
| OB2126FQ | 5~9 | 5V/3.8A | 30 | / | 400KHz | 5V/80mA | 11.5 | Yes | 2.8 | Yes | Yes | 14.3 | Yes | QFN48 |
| 9V/2A | ||||||||||||||
| 12V/1.5A | ||||||||||||||
